DIP DIL Switch 2 Way Tiny Piano SMD S3094

DIP DIL Switch 2 Way Tiny Piano SMD S3094

$2.60
$2.60
Sale Sold out
Taxes included.

Gold plated contacts and pins. Durable self wiping contacts.


A: 11.52

Specifications

  • Rating: 50V DC 100mA continuous, 24V DC 25mA switching
  • Contact resistance: 50mΩ max. initially
  • Insulation resistance: 100MΩ min.
  • Operation life: Average 2000 min.
  • Dielectric breakdown voltage: 500V AC min.
  • Operation force: 1000gf max.
  • Terminals: Gold plated
  • DIL switch package width: 11.52mm
