HDR-30-24 36W 24VDC 1.5A DIN Rail Switchmode Power Supply M8393

SKU: 9321758186862


The Mean Well HDR-30-24 is a 36W DIN rail mountable power supply with an output voltage of 24V. The ultra-slim design is ideal for lower current DC power applications in a standardised DIN rail housing to suit mounting to asymmetrical “G” or 35mm top hat type DIN rails. Each unit measures only 90mm high and is supplied in 35mm and 52.5mm widths.

Mean Well Model: HDR-30-24
Output: 1.5A
Rated Wattage: 36W
Inrush Current: 25A
Efficiency: 88%
Input Range: 85-264V AC, 120-370V DC
Input Frequency: 47-63Hz
Warranty: 3 years
Weight: 120g
Dimensions: 35 x 90 x 54.5mm
