JBL Stage A135C Centre Channel Speaker STAGEA135CBK

JBL Stage A135C

Enjoy enhanced dialogue from your favourite movies and TV shows with your amplifier and the JBL Stage Series A135C two way centre channel speaker. It features a 1" aluminium dome tweeter and six 3" poly-cellulose woofers, and accepts 20 to 150 W of power from your amplifier. The side firing, bass reflex ports help enhance the low frequency response. As a centre channel, when integrated with the rest of your home theatre system, it will produce primarily on-screen dialogue rather than the sound effects coming from the rest of your speakers.

Key Features

• 6 x 3" (76 mm) Poly-cellulose low frequency woofers
• High Definition Imaging (HDI) waveguide
• 1" (25 mm) aluminium dome tweeter
• Recommended amplifier power: 20 - 150 W
• Frequency response: 75 Hz - 40 kHz
• Sensitivity: 90 dB @ 1 m, 2.83 V
• Nominal impedance: 6 ohms
• Crossover frequencies: 2.6 kHz
• Enclosure type: Bass reflex via side firing tuned ports
• 2-way
• Dimensions (W x D x H): 745 x 166 x 104 mm

• Weight: 7.45 kg
• Warranty: 5 Years
• Colours: Black or Wood
