LED 5mm 7500mcd Clear Green ZD0172

Name: LED 5mm 7500mcd Clear Green ZD0172
Brand: Electus
SKU: 9319236889930
Price: 2.25 AUD
Availability: InStock

$2.25

Sale Sold out

Taxes included.

Green 5mm LED 7500mcd Round Clear

Diameter : 5mm

Packaged Volume : 0l

Packaged Weight : 0kg

Packaged Length : 0.5cm

Packaged Width : 0.5cm

Packaged Height : 3.5cm

LED Type : 5mm Standard LED

Illumination Type : Single Colour

Light Colour : Green

Light Wavelength : 525nm

Lens Type : waterclear

Viewing Angle : 30°

Intensity : 7500mcd

V_{f (typ)} - Typical Forward Voltage : 3.5V

I_{f (typ)} - Typical Forward Current : 20mA

I_{f (max)} - Maximum Forward Current : 30mA

Resistor for 5VDC : 75Ω

Resistor for 9VDC : 270Ω

Resistor for 12VDC : 430Ω
