This waterproof power over ethernet (PoE) splitter is Ideal for cameras in exposed installations, this waterproof splitter allows you to power non PoE equipped devices from a 802.3af Power Over Ethernet RJ45 cable (70m max). 12V, 2A max.
Features
- 1 LAN-In (Data + Power) +1 LAN-Out (Data Only)
- Take Power from PSE
- 5v 12v 24v 48v Passive POE
- 5v 12v 24v 48v Cheap price of cable type passive POE splitter
- Splitter: RJ45 Female to RJ45 Male + Power Out
- Passive PoE - means that input and output voltage are equal.
- Works with all DC powered non-PoE devices
- Supports 5V, 12V, 24V, 48V
- Power supply required for power input - simply use the power supply (wall transformer) that is provided with the device you are trying to power.
- Uses industry standard 5.5mm x 2.1mm power plugs
- Can work up to 150ft (depending on the quality of the cable and the power draw of the device)
Specifications
Power Output Specification
- Data : Pins 12 / 36
- Power : Pins 45(+) / 78(-)
- Data in : PC / Hub / Switch
- Connector : RJ-45
- Wires : UL standard
- Data rate : 10/100 Mbps
- Ethernet cable : TIA/EIA 568 Cat.5 or Cat.5e
General Specification
- Operation Temperature : 0°C ~ +40°C
- Storage Temperature : -40°C ~ +70°C
- Operation Humidity : 10% - 80% RH
- Storage Humidity : 5% - 90% RH
- Case of material : PVC
- DC Plus & Jacks : 2.1x5.5x12mm /2.5x5.5x12mm
- Cable Length : 150mm +10mm
