TL-SF1008D 8-port 10/100Mbps Fast Ethernet Switch provides 8 10/100Mbps Auto-Negotiation RJ45 ports. All ports support Auto MDI/MDIX function, eliminating the need for crossover cables or Uplink ports. The Switch is Plug-and-Play and each port can be used as general ports or Uplink ports and can be simply plugged into a server, a hub or a switch, using straight cable or crossover cable.
The TP-LINK TL-SF1008D 8-port 10/100M Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-performance, seamless and standard upgrade to improve your old network to a 100Mbps network. It will boost your network performance up to full duplex data transfer. Its wire-speed switching that forwards packets can be as fast as the speed that your network delivers those packets to them.
Features
- Complies with IEEE802.3, IEEE802.3u standards
- 8 10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Supports IEEE802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
- Supports MAC address auto-learning and auto-aging
- LED indicators for monitoring power, link, activity
- Plastic case, desktop or wall-mounting design
- External Power Adapter supply
Specifications
- Standards: IEEE802.3, IEEE802.3u
- Ports: 10/100Mbps Auto-Negotiation ports
- Cable Type: cat. 5, cat. 5e Ethernet Cable for 100Mbps, Cat. 3, 4, 5 for 10Mbps
- Data Transfer Rate: Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex) Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex)
- LED Indicators: Power, Link/Act
- Transfer Method: Store-and-Forward
- MAC Address Learning: Automatically learning, automatically Update
- Frame Filtering and Forward Rate: 10Mbps: 14880pps, 100Mbps: 148800pps
- Power Supply Output: 9V~ 50-60Hz, 0.8A
- Dimensions (W×D×H): 140 × 85 × 30mm
