Non-Sealed type, suitable for flow soldering
Specifications
- Max switching voltage: 380V AC, 42V DC
- Max switching current: 10A
- Max VA (Watts): 1250VA (280W)
- Contact material: Silver Cadmium Oxide
- Coil resistance: 240Ω
- Max coil power: 600mw
- Insulation resistance: >100MΩ @ 500V DC
- Dielectric strength (for 1 min):
- 500V AC between open contacts
- 500V AC between coil & contact
- Electrical life: 100,000 operations
- Mechanical life: 10 million operations
- Dimensions:˜15W x 12L x 12Hmm
