Rocker Switch SPST Red LED Round (Square Facia) S3190

A stylish round panel mount SPST alternate rocker switch with a square facia and red LED. Low profile design protrudes just 3.5mm from the panel surface. Contact rating of 10A @ 250V AC.

NOTE: The LED terminals are the two smaller terminals.

Diagram

Switch Type: SPST Alternate
Indicator: Red LED
Contact Rating: 6A @ 250V AC
Panel Cutout: 20mmØ
Panel Thickness: 6mm Max.
LED Indicator Power Requirements: 1.85V dc, 10mA.
