This pack provides the components required to connect compatible Redback® products to an Ethernet network. Designated Redback® products have configuration software allowing remote setup & configuration via the Serial-to-Ethernet Converter (Altronics D4231) supplied in this pack.
Compatible Products:
A 4500C 24 Hour 7 Day Timer With Evac Tone Generator
A 4505C 7 Day Timer With Lockdown & Fire Alarm Control
A 4510B Yearly Programmable School Timer
Package Contents:
1x Serial-to-Ethernet Converter (D4231)
1x Proprietary Redback Adaptor Board
1x 1m CAT6 Patch Lead
Features
- Supports auto-MDI/MDIX
- Supports TCP/IP server, TCP/IP Client & UDP
- Baud rate 300bps-230400bps
- Supports Modbus RTU
- Reload function
- RS485 support full duplex and half duplex
Specifications
- Chipset: IP210
- Ports: 1 port 10/100M Auto MDI-MDIX RJ45，1port RS232, 1port RS485/422
- Standards: IEEE 802.3、IEEE 802.3u、IEEE 802.3x、IEEE 802.3az
- Network: 10Base-T, cat3 or above UTP, 10Base-Tx, cat5 UTP
- Data rate: 10/100M
- Forwarding rate: 10 Mbps / 14,880 pps ,100 Mbps / 148,800 pps
- LED Indicators: Link/Act, Power, System, TX/RX
- Baud rate: 110bps~256000bps
- Operation modes: TCP Server, TCP Client, UDP
- Dimensions: 86W x 84H x 25Dmm
- Power Input: 9V-54V DC
- Power Consumption: Max 1.8W
- Operating Temperature: -10°C to 55°C
- Relative Humidity: 10%-90% (non-condensing)
Device Defaults
- ID: admin
- Password: system
- IP address: 192.168.2.1
- Operation mode: TCP server
- Transmission Mode: RS232
- Baud rate: 57600bps
- UART parameters: 57600, 8, N, 1
- Local port TCP 23, UDP 21
