Screw Terminals 6 Way Barrier Terminal With Cover HM3168

Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5

Specifications

AC current rating : 25A

Packaged Volume : 0.03l

Packaged Weight : 0.02kg

Packaged Length : 7.6cm

Packaged Width : 2.7cm

Packaged Height : 1.6cm

Type : Screw Terminal

Device : Terminal

Attachment Method : Solder Tag

Number of Contacts : 6pc

Terminal Spacing : 9.5mm

Insulation Dielectric Voltage Rating : 2V

Insulation Resistance : 500MΩ
