HDMI Splitter 4K 1x4 V2.0 18GBps Bandwidth A3135F

SKU: 9321758228203


This is a high performance V2.0 - 1x HDMI input to 4x HDMI output splitter. The system supports all 3D TV formats in addition to all HDTV formats up to 4K Ultra HD (3840 x 2160p) @60Hz video. It also supports HDCP 2.2 compatibility.


  • Simultaneously displays an UItra Hi-Def source on up to four UItra HD displays
  • Video Resolutions up to UItra HD 4Kx2K (3840x2160p)@60Hz YUV 4:4:4
  • Three kinds of EDID handling abilities
  • HDCP2.2/1.4 Compliant
  • 36 bit Deep Color
  • LPCM 7.1, Dolby TrueHD, Dolby digital Plus, and DTS-HD Master Audio
  • Bandwidth 18Gbps
  • Supports HDR
  • Online firmware upgrade via Micro USB Port



  • Input Signal: HDMI Signal
  • Output Signal: HDMI Signal
  • Frequency Bandwidth: 6.0Gbps 600MHz per channel
  • Frequency Range: 50/60Hz
  • Interlaced resolution (50/60Hz): 480i, 576i, 1080i
  • Progressive resolution (50/60Hz): 480p, 576p, 720p, 1080p, 4K
