Microcontrollers Microchip ATSAMD21G17 Microcontroller 48 Pin TQFP Y1860
Microcontrollers Microchip ATSAMD21G17 Microcontroller 48 Pin TQFP Y1860
Regular price
$10.25
Regular price
Sale price
$10.25
Unit price
per
Taxes included.
Couldn't load pickup availability
A low-power, high-performance Microchip's ARM Cortex-M0+ based flash microcontroller, the ATSAMD21G17 is ideal for a wide range of home automation, consumer, metering, and industrial applications. As used in the Arduino Zero.
Features
- 128KB of flash and 16KB of SRAM
- Up to 48MHz operating frequency
- Six serial communication modules (SERCOM) configurable as UART/USART, SPI or I2C, three 16-bit timer/counters, 32-bit Real-Time Clock and calendar, 20 PWM channels, one 14-channel 12-bit ADC, one 10-bit DAC
- Full Speed USB 2.0 Device and embedded Host
- Support for up to 120 touch channels
- 1.62V to 3.63V power supply
- Easy pin migration to SAMD21G and SAMD21J devices
- Supported by Atmel Studio, ASF and the SAM D21 Xplained Pro kit
- 38 GPIOs
- Operates between-40ºC and 85ºC
Specifications
- Family SAM D21
- Max Speed MHz 48
- Program Memory Size (KB) 128
- RAM (KB) 16
- Auxiliary Flash (KB) 0.064
- Temperature Range (C) -40 to 85
- Operating Voltage Range (V) 1.62 to 3.63
- DMA Channels 12
- SPITM 6
- I2CTM Compatible 6
- Peripheral Pin Select (PPS) Crossbar Yes
- USB 1
- USB Interface Host, Device
- A/D channels 14
- Max A/D Resolution 12
- Max A/D Sample Rate (KSPS) 350
- Input Capture 6
- Motor Control PWM Channels 6
- 16-bit Digital Timers 5
- Parallel Port GPIO
- Comparators 2
- Internal Oscillator 32khz, 32Khz ULP, 8Mhz
- RTCC Yes
- I/O Pins 38
- Pin Count 48
